FEATURES
- 40 rear loading threaded pins with nyloc nuts
- DU plus cartridge bearing axle system
- Thin leading edge chamfered design to deflect off obstacles
- Wide platform design for increased stability
- Contoured shape provides ultimate connected feel
SPECS
- Weight: 355g
- Platform Size: 115x105mm
- # of Pins: 10 per side
- Axle Material: Black chromoly steel
- Height: 18.5mm (13.3 at the leading edge)
- Pin to Axle distance: 108mm
- Color: Stealth Black
- Body Material: Nylon Composite
INSTRUCTIONS
Install with 6mm Hex or 15mm pedal wrench. Torque to 35Nm (25 ft-lbs) Min
